Brief introduction:
TiFe Cored Wire is a composite material made of Titanium iron alloy broken into a certain size and then rolled with cold rolled low carbon steel strip. It is mainly used for steel making and casting.
Features and usage:
* Titanium-iron cored wire is a kind of strong oxidant, and its deoxidizing capacity is much higher than that of silicon and manganese.
* The ti-Fe cored wire is fed into the steel, the reaction is stable, uniform, avoid secondary oxidation, and the inclusion floats quickly.
* The composition of molten steel can be controlled effectively and the alloying elements in steel are stable.
* Reduce alloy consumption, reduce production cost, greatly increase alloy recovery, increase steel strength, corrosion resistance and stability, and improve cast iron performance.
Model | Technical Index (%） | |||||||
Ti | Al | Si | P | Cu | C | S | Mn | |
≤ | ||||||||
FeTi30-A | 25-35 | 8.0 | 4.5 | 0.05 | 0.4 | 0.10 | 0.03 | 2.5 |
FeTi30-B | 25-35 | 8.5 | 5.0 | 0.06 | 0.4 | 0.15 | 0.04 | 2.5 |
FeTi30Al4-A | 25-35 | 4.0 | 4.5 | 0.04 | 0.4 | 0.10 | 0.03 | 2.5 |
FeTi30Al4-B | 25-35 | 4.0 | 8.0 | 0.05 | 0.4 | 0.10 | 0.03 | 2.5 |
FeTi40-A | 35-45 | 7.0 | 2.5 | 0.04 | 0.2 | 0.10 | 0.02 | 2.5 |
FeTi40-B | 35-45 | 9.0 | 4.5 | 0.04 | 0.4 | 0.15 | 0.03 | 2.5 |
FeTi70 | 65-75 | 5.0 | 0.7 | 0.05 | 0.3 | 0.30 | 0.04 | 1.0 |
Wire technical specifications:
(1) Wire diameter: 13-13.5mm.
(2) Thickness of the steel: 0.4mm±0.05mm.
(3) Powder contain: 350g/m Min
(4) Ratio powder/steel: 60/40.
(5) Wire length: 5000-5500m.
(6) Coil weight: 1000-2000kgs.
(7) Coil width: 600-800mm
(8) Wire winding: horizontal
(9) Packing: in steel cages covered with plastic
